Sting 11 B and Sting 11 B Premium are fully automatic high-speed pre & post vacuum steam sterilizers, autoclaves, designed with the highest quality for sterilization of wrapped materials, hollow instruments and porous loads in hospitals, private clinics and dental and veterinary offices.
These models have been sold to 40+ countries in Europe, the Middle East, Latin-America, Africa and Australia, and are highly recommended by doctors and professionals.
All components used have been selected carefully, meeting the highest quality standards and requirements from leading companies with the most advanced technologies around the world.
The Sting 11 B bench-top autoclave models are equipped with a 25-liter jacketed chamber made of stainless steel 316L, which conforms to the Pressure Equipment Directive (PED).
The design of these table-top autoclaves is modern, ensuring reliable operation, incorporating high-tech features. Behind its success is a team of multi-disciplinary engineers, who have developed sterilization equipment on OEM basis for leading manufacturers around the world, for more than 20 years.
With the high-speed integrated steam generator, the steam is always ready, resulting in fast sterilization cycles. Using a built-in powerful dry membrane vacuum pump, water is no longer needed during the vacuum stage, and is thus environmental friendly.
All autoclaves are equipped with Energy Saving Mode, which reduces power consumption by 30%, and activated if the autoclave is not in use after a certain period of time.
Through the numerous safety features, the Sting 11B steam sterilizers meet the highest standards and requirements for quality, safety and operation (EN 13060 – Small Steam Sterilizers standard; Pressure Equipment Directive (PED); Medical Device Directive MDD 93/42/EEC; EN 60601-1, EN 61010-1 and EN 61326 safety standards, etc. and CE approved).
Operating the unit is very simple, thanks to the microprocessor based control system and the friendly Graphic Touch-Screen User Interface, available for users in a variety of languages. The steam sterilizers have fully automatic door locking system, enabling opening and closing with just one button.
Sting 11 B Series offer 7 preset cycles, 5 sterilization cycles with sterilization temperatures of 121°C and 134°C and 2 test cycles to assure a proper sterility level. Up to a total of 20 cycles can be custom designed according to the user’s needs.
Each cycle can be documented by the printer which records the cycle parameters or can be collected through an SD card, providing environmentally friendly, paperless recording.
In addition to the stand-alone unit, a water purification system is available in order to improve the quality of the water and to avoid the need to manually refill the water reservoir.
With a range of accessories these autoclaves can be easily customized according to the customer’s requirements.
Easy to install, (due to its utilities free concept,) just plug into the power source and start sterilizing. The modular design of all internal and external components, together with the self-diagnostic system ensure easy maintenance, resulting in reliable service and performance and satisfied operators.
Sting 11 B Family can be used to sterilize dental hand pieces, laparoscopes, wrapped surgical sets, etc., and provides the most advanced and best solution for hospitals, dental, veterinary and small clinics.
|Model Sting 11 B Series||Sting 11B||Sting 11B Premium|
|Chamber dimensions, Inner Dia. x Depth||261 x 472 mm|
|Chamber volume||25 liters|
|External dimensions W x H x D||534 x 475 x 609 mm|
|Approximate Weight||70 kg|
|Power supply *||1 ph. 220 V, 50/60 Hz|
|Power with steam generator||3000 W|
|Available sterilization cycles||Flash 134 °C / Unwrapped 134 °C / Wrapped 134 °C / Prion 134 °C / Porous 121 °C|
|Available test cycles||Bowie & Dick test / Vacuum test|
|Touch-screen display||LCD 4.5’’ Blue/White Graphic||LCD 5.7’’ Color Graphic|
|Cabinet||Painted quality steel||Stainless steel|
* Adjustable to different voltage system
Options and Accessories – Customize Your Autoclave
|Printer – Each cycle is documented by the integrated printer which records the preset and actual parameters of the cycle: the selected sterilization or test cycle, cycle parameters, date, time, temperature, pressure, errors, etc.|
|SD card – Sterilization cycles’ data can be collected online on a SD Card through an optional SD Card Slot. Collected data can be downloaded into a computer equipped with proprietary PC Software.|
|Pressure gauge – Analog pressure gauge installed on the front of the sterilizer machine to indicate chamber/jacket/steam generator pressure in addition to the LCD Display.|
|Reverse osmosis system (water purifier) – A Reverse Osmosis system shall be used to improve the quality of the water used to generate steam in the electric steam generator and to secure fully automatic operation. The use of mineral-free water will contribute to better performance and longer life of the autoclave’s chamber.|
|HMI PC software (Monitoring and Documentation Software) – Powerful PC Windows based software is available for monitoring, logging sterilization cycle parameters, and providing complete control and service over the autoclaves.|
|Tray holder and trays – Stainless steel tray holder with up to 6 trays.|
|Sterilization wire mesh baskets, dental aluminum containers, pouch racks and cassettes – Several accessories in different sizes are available to fulfill customers’ needs.|
